Product Detail

The F3DIO16/801 is a compact, safety-related remote I/O module designed to interface safely with high-integrity automation systems. It extends the number of digital inputs and outputs

in a distributed safety control system such as HIMax or HIMatrix by communicating with the main safety controller over safeEthernet.

 It does not execute user programs by itself but serves as an I/O expansion unit for field signals.

FAQ of  F3DIO16/801

Q1. What is the primary purpose of the F3DIO16/801 module?
A1. It expands digital I/O capacity in a safety automation system, reporting inputs and setting outputs safely via safeEthernet to a main safety controller.

Q2. How many channels of digital inputs and outputs does it have?
A2. It provides 16 digital inputs, 8 digital outputs (two-pole outputs), and 2 pulsed outputs for diagnostic purposes.

Q3. Can it be used independently?
A3. No — it must be connected to a safety controller (e.g., HIMax or HIMatrix) which manages logic and

communicates with the module.

Q4. What safety standards does it comply with?
A4. Certified up to SIL 3 (IEC 61508/61511), Cat. 4 PL e (EN ISO 13849-1), and suitable

variants are rated for hazardous area installation (Zone 2).

Why choose us

1.We will provie you the product info and picuture
2.Large stock, fast delivery
3.Competitive prices and immdiate quotation
4.Professional service,professional technical support
5.Warranty time is one year.
6.Strict test machine before shipment.
7.We could help you to get any components which is difficult to get.

Application scenario

Petrochemical industry: Monitor pipeline pressure and valve status to prevent leaks or explosions.

Electric power industry: Ensure the safe operation of power generation units and substations, and implement emergency shutdown functions.

Rail transportation: Monitor train door status and signal systems to ensure train safety.

Mechanical manufacturing: Control safety interlocks for dangerous machinery (such as stamping machines, robots).

Product description

Manufacturer: HIMA

Product No.: F3 DIO 16/8 01 F3DIO16/801

The Himatrix F3 DIO 16/8 01 is a versatile and reliable I/O module seamlessly integrated into industrial automation systems, providing robust data acquisition and control capabilities. Designed for demanding industrial environments, it excels in performance and reliability, making it invaluable for a wide range of applications.

Technical Specifications:

• Model Type: F3 DIO 16/8 01

• Manufacturer: Himatrix

• Application: Industrial Automation

• Number of Channels: 16 Inputs, 8 Outputs

• Input/Output Type: Digital

• Input Voltage Range: 24 VDC

• Output Voltage Range: 24 VDC

• Input/Output Current: 1 A per channel

• Isolation Voltage: 2500 V RMS

• Operating Temperature Range: -40°C to +70°C

Unwavering Reliability in Harsh Environments:

The Himatrix F3 DIO 16/8 01 is meticulously engineered to withstand the rigors of industrial environments. Its robust construction, high-quality components, and adherence to stringent quality standards ensure unwavering reliability even in harsh conditions, minimizing downtime and maximizing operational efficiency.
