Products Description
Product Overview
The Applied Materials AMAT 0041-48723 is a high-precision RF matching network module designed for advanced semiconductor manufacturing processes, specifically optimized for plasma-enhanced chemical vapor deposition (PECVD) and etch systems. As part of Applied Materials’ Centura® equipment platform, this critical component ensures precise impedance matching between RF generators and process chambers, enabling stable plasma control in sub-7nm node fabrication. The AMAT 0041-48723 incorporates adaptive frequency tuning technology, maintaining voltage standing wave ratio (VSWR) below 1.5:1 even under dynamic load conditions, crucial for atomic-layer etching applications. Its dual-directional coupler design provides real-time forward/reflected power monitoring with 0.1% resolution, supporting fault detection in 300mm wafer processing tools.
Engineered for 24/7 semiconductor fab operations, the AMAT 0041-48723 features liquid-cooled RF contacts rated for 10,000+ maintenance cycles, reducing particle generation in cleanroom environments. The module’s proprietary SmartMatch™ algorithm automatically compensates for electrode wear and process kit variations, achieving <5ms impedance matching time across 1-100MHz frequency range. With built-in SEMI E142 compliance, the AMAT 0041-48723 enables seamless integration into advanced process control (APC) frameworks for EUV lithography tool clusters.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 0041-48723 |
| Manufacturer | Applied Materials (AMAT) |
| Product Type | RF Matching Network Module |
| Frequency Range | 1-100 MHz (auto-tuning) |
| Max Power Handling | 5000W continuous (6000W peak) |
| VSWR Tolerance | <1.5:1 @ 13.56MHz |
| Matching Speed | <5ms typical |
| Cooling Method | Closed-loop deionized water |
| Interface | SEMI E142-compliant digital I/O |
| Operating Temperature | 15°C-35°C (chassis) |
| Storage Temperature | -20°C to +70°C |
| Dimensions | 480 x 320 x 150 mm |
| Weight | 18.5 kg |
Key Features Description
Plasma stability control:
The AMAT 0041-48723 utilizes phase-compensated matching topology to eliminate harmonic distortions in high-aspect-ratio etching processes. Its dynamic load adaptation maintains ±0.5% power delivery accuracy during RF pulsing (1-100kHz), critical for 3D NAND structure formation.
