Products Description
I. Basic Positioning
Model: T8314 (often with version suffix, such as T8314C)
System: Trusted TMR / AADvance SIS
Function: Fibre TX/RX Unit, Extended Trusted Expander Bus (Expansion Bus)
Certification: SIL3, TÜV, CE, UL
II. Core Parameters (Official Version)
Power Supply: 24VDC (dual diode or redundant power supply)
Fibre: Single Mode (SM), SC interface (1 for Tx/Rx each)
Maximum Distance: 10 km (Single Mode)
Bus Rate: Consistent with Trusted Expansion Bus
Operating Temperature: -40℃ ~ +70℃
Installation: DIN rail or rack installation
Size (approx.): 100×80×30 mm
Weight (approx.): 200 g
Key Features
TMR Triple Redundancy: Three independent transmission and reception paths, seamless failover at a single point.
Long-distance Isolation: Optical fibre transmission, resistant to EMI/RFI, suitable for strong interference plant areas.
Redundant Power Supply: Dual 24VDC inputs, diode-OR anti-reverse connection.
Hot Swap: Online replacement, no impact on operation.
Complete Diagnosis: Link, power supply, channel status can be monitored by the system.
IV. Typical Applications
SIS/ESD Safety Instrumentation System: Petrochemical, natural gas, power station, pharmaceuticals.
Remote I/O Rack: Optical connection between the main control room and the remote cabinet at the site.
High-reliability Interlock: Key units, combustion management (BMS), emergency stop.
V. Related Base / Accessories of T8314
Recommended Base: Direct DIN rail installation, no need for a dedicated backplane; compatible with T8300/T8311 and other series racks.
Paired Modules: Both ends use T8314 to form an optical fibre link.
VI. Model Clarification (Similarities)
T8314: Optical Transceiver (This article), Expansion Bus Optical Extension.
T8302/T8311: Controller / Communication Module, Different functions.
9802/9852: AADvance Series I/O Base, belong to different product lines from T8314.
