Functional Features

Mechanical Carrier: Module fixation, guide rail mounting, vibration resistance

Electrical Backplane: 24VDC power supply, signal isolation, dual-channel redundant communication

Safety Isolation: 2500V RMS channel isolation, compliant with SIL3 / TÜV certification

Hot Swap: Online module replacement without system interruption

Key Specifications (98021 / 98522)

Manufacturer: ICS Triplex (Rockwell Automation)

Power Supply: 24VDC (power drawn from backplane)

Slot Current: 98021 ≈ 3A; 98522 – 5A per slot (total 10A)

Communication: Backplane bus, Ethernet, Modbus

Isolation: 2500V RMS (between channels)

Temperature Range: -40°C to +70°C

Protection: IP20

Dimensions: Standard 19-inch rack-mount, 4U height

Weight: Approx. 2.5 kg

Compatible Modules

9802*1 → T9802: 16-point 24VDC digital input, dual-channel redundancy

9852*2 → T9852: Supports digital and analog I/O modules, compatible with redundant configuration

Typical Applications

SIS safety systems in petrochemicals, natural gas, power generation, pharmaceuticals, etc.

Critical interlocks, emergency shutdown (ESD), burner management (BMS)

High availability, fault-tolerant, SIL3-level safety control

Model Differentiation

9802*1: Base board (Board Base) + T9802 module

9852*2: Dual-slot base, no module included

T9802: Module itself, base not included
