product description:

ABB ACU-01B | 3HNA024871-001 | robot spray accessory controller.The ABB ACU-01B 3HNA024871-001 02 is a control unit that is typically used in conjunction with ABB robot systems. It is used to control and monitor the movement and operation of robots, including their motion, trajectory planning, speed, and position control.related products：DSQC652 3HAC025917-001 I/O Module ，ABB ACU-01 | 3HNA013719-001

I. Product Basic Information

Model: ACU-01B

Part Number: 3HNA024871-001 (Upgraded replacement for older model: 3HNA013719-001)

Origin: Norway

Compatible Models: ABB IRB5400/IRB5500/IRB580 series electrostatic spray robots (main models used in automotive body painting lines)

Net Weight / Dimensions: 3.66 kg; 210 (L) × 160 (W) × 140 (H) mm

ICore Features (3 Independent Pneumatic Closed-Loop Controls)

Three-channel independent pneumatic closed-loop regulation: PID precise pressure control for atomizing air, shaping air, and turbine drive air—ensuring millisecond-level response, stable paint mist atomization, and consistent spray pattern width to guarantee uniform film thickness and reduce paint consumption.

Integrated solenoid valve assembly + pressure monitoring: Built-in pressure sensors and high-speed electrically controlled valves enable real-time pressure data acquisition and online adjustment of pressure parameters via robot programming.

Valve position & fault self-diagnosis: Equipped with status indicator lights to monitor air leakage, blockage, or valve failure in real time; alarm codes can be remotely read via RobotStudio software.

Bus communication: Built-in RJ45 Ethernet (EtherNet/IP/Profinet), directly connected to the IRC5 robot controller for high-speed exchange of spray recipe parameters.

Electrical & Environmental Specifications

Power Supply: 24VDC industrial power

Operating Air Pressure Range: 0–10 bar industrial compressed air

Operating Temperature: 0°C to +55°C (specifically designed for humid, dusty conditions in paint booths)

Protection Rating: Electrical chamber IP20; pneumatic valve body IP65 dust- and waterproof, suitable for harsh environments in paint shops

Communication: 1× RJ45 10/100M Ethernet; terminal block DI/DO digital input/output interfaces

Application Scenarios

Automated topcoat and intermediate coat painting lines for automotive white bodies

Robot-assisted electrostatic spraying for automotive components, wheels, and bumpers

Automated coating production lines for aerospace and construction machinery enclosures
